Axial Flow Exhaust Fan

Product Description

Factory direct selling industrial exhaust fan Farm house workshop poultry axial flow exhaust fan

Fans Mainly consists of the blade ,motor,frame , protect net , bracing cage ,shutters .The motor drives blade to cause air flow and louver window can open and close automatically to keep the dust from entering .AD / CAM optimization design and manufacturing are adopted,and quality control is strict. Huayi's heavy hammer fans have the following characteristics: high total pressure, large air volume, low noise, low energy consumption, stable operation, long service life,

Structure diagram Detail image Different models

Sepeclfcation

Blade

Diameter(mm)

Blade Rotationnal

Speed(rpm)

Motor

Rotational(rpm)

Airflow

(M3/h)

Noise

(db)

Import Power

(KW)

LWH(mm)

HYZ-480

380

1400

1400

3000

≤70

0.18

480*480*320

HYZ-600

500

1400

1400

5600

≤70

0.37

600*600*320

HYZ-800

710

660

1400

17500

≤70

0.37

800*800*400

HYZ-900

750

630

1400

20000

≤70

0.55

900*900*400

HYZ-1000

900

610

1400

24800

≤70

0.55

1000*100*400

HYZ-1100

1000

600

1400

32000

≤70

0.75

1100*1100*400

HYZ-1220

1100

460

1400

38000

≤70

0.75

1220*1220*400

HYZ-1380

1250

457

1400

42000

≤70

1.1

1380*1380*400

HYZ-1530

1400

320

1400

55000

≤70

1.5

1530*1530*400

Details Images

Shutters

1. Material: Hot Galvanized sheet with zinc thickness of 275g/sqm

2. Shutter Fixed Parts: High quality nylon.

Advantage:

High anti-corrosion performance, open flexibly, long service life, no deformation ,no rust, running stable.

Motor

100% pure copper wire.Motor Protection Grade: IP55 Insulation Class: F grade. Motor voltage and frequency can be customized.Both Chinese famous motor and Siemens motor are available.

Fan Blades

1. Material :430 stainless steel, thickness 1.2mm

2. Diameter: 1270mm

Advantage:

Large air flow, no deformation, no fracture, no dust, attractive and durable.

Note:

Blade material also have galvanized sheet, aluminum alloy for option

Belt Pulley

1. Material: High strength aluminum-magnesium alloy by die-casting.

2. Blast-sanding treatment, eliminate internal stress to improve its own rigidity and stability

Advantage:

Light weight, Low vibration ,attractive appearance.

Opening system

Heavy hammer exhaust fan

Material: High quality Nylon PA66

Advantage:It can keep the shutters open at complete 90 degree to ensure the lowest air resistantce and biggest air volume

Case Display

exhaust fan are widely used in agriculture and industry's ventilation and cooling system. For example, animal husbandry ,poultry house , greenhouse ,factory workshop, textile, chemical and so on.
